Mesa 3 Windows Rugged Tablet

Description

Overview

The Mesa 3 rugged tablet running Windows 10 offers powerful new functionality while retaining impressive features from the popular Mesa 2 rugged tablet. Its Quad-core Pentium processor is ready to run even the most demanding field data collection application, and its rugged ergonomic design is ready to handle a long day on the job in some of the harshest environments out there. Ready to experience Juniper Rugged?

Built Juniper Rugged™

Meeting IP68 and MIL-STD-810G ratings, the Mesa 3 is waterproof, dustproof, and shockproof. Rest assured rain,
extreme temperatures, and dirt won’t stop a productive workday.

Advanced Processing Power

Expect lightning-fast speeds all day long with the Mesa 3’s Quad-core Intel® Pentium N4200 processor and 8 GBs of system memory (RAM). Running a full Windows 10 OS, this device is made to handle large files and detailed maps.

All-Day Usability

From its ergonomic enclosure to its sunlight-readable display to its 15-hour battery life, the Mesa 3 is made for long days on the job.

Carefully Designed and Supported

It’s more than a rugged tablet. Designed and assembled in the United States, the Mesa 3 promises device longevity
and data protection. If it becomes necessary, each device is proudly supported by live and personalized customer support.

Features

• Waterproof, dustproof, shockproof
• Extreme temperature endurance
• Ergonomic design for minimal user fatigue
• All-day battery life
• Large 7-inch sunlight-readable display
• Racing-fast processor options
• Designed and assembled in the United States
• Live and individualized customer support
• Customizable
• Optional Class 1, Div 2 certification for hazardous locations

Technical Specifications

Processor

• Quad-core Intel® Pentium N4200

Operating System & Software

• Microsoft® Windows 10
• Multiple languages supported (English, French, Spanish, German, Portuguese)

Memory

• 8 GB LPDDR4

Storage

• 128 or 256 GB Flash Storage, MicroSDXC card slot

Wireless Connectivity

• Long-range Bluetooth® Smart Ready wireless technology, v5.0 + EDR, Class 1.5, BLE support
• Wi-Fi 802.11 a/b/g/n/ac, 2.4 GHz and 5 GHz
• 2×2 MIMO
• 4G LTE multi-carrier capable

Graphics

• Intel® HD Graphics

Display

• Active viewing area: 7 in (178 mm)
• Resolution: WXGA (1280 x 800)
• High-visibility backlit LCD for best-in-class sunlight view-ability
• Portrait or landscape orientation with automatic screen rotation

Touchscreen

• Projected capacitive multi-touch interface for use with gloves, small tip stylus, and in wet conditions
• Optically bonded for increased visibility and strength
• Chemically-strengthened Dragontrail™ High Ion-Exchange (HIE™) cover glass for excellent impact and scratch resistance

Keypad

• Adjustable LED backlit keys
• Four-way directional navpad
• Windows/home key
• Power key
• Enter key
• Three user-programmable function keys
• OEM configurable/customizable

Juniper Rugged^TM

• IP68 waterproof & dustproof – Water: 1.4 m (4 ft 7 in) for 2 hours
• Operating temperature: -4 °F to 122 °F (-20 °C to 50 °C)
• Storage temperature: -22 °F to 158 °F (-30 °C to 70 °C)
• Shockproof: multiple drops from 4 ft (1.2–1.5 m) onto concrete
• Designed to meet MIL-STD-810G test procedures: Method 500.5 Low Pressure (Altitude); Method 501.5 High Temperature; Method 502.5 Low Temperature; Method 503.5 Temperature Shock; Method 506.5 Rain; Method 507.5 Humidity; Method 510.5 Sand and Dust; Method 512.5 Immersion; Method 514.6 Vibration; Method 516.6 Shock

Ports

• 12V DC power input jack
• USB 3.0 x 1
• 3.5 mm audio jack
• Optional RS-232 9-Pin D-Sub connector with 5V DC or 12V DC power output
• Docking connector (Pwr, USB 2.0, HDMI, & ethernet)
• Loud output speaker for noisy environments
• Dual digital microphone input

Battery

• Removable Li-Ion battery, 43.2 Whr
• Operates 8–10 hours on one charge
• Removable battery, easily changeable in field
• Optimized for strong performance in cold temperatures
• Excellent lifecycle performance
• Optional internal 21.6 Whr battery provides hot-swap capability and an additional 4–5 hours runtime

Physical

• Size: 5.40 in (W) x 8.48 in (L) x 1.36 in (D) (137 mm x 215 mm x 35 mm)
• Weight: 1.5–2 lbs (680–907 g) depending on battery and expansion configuration
• Durable, chemical- and shock-resistant design
• Easy-to-grip, impact-absorbing, overmolded bumpers
• Lightweight and ergonomic design

GPS/GNSS (Geo Models Only)

• 2 to 5 meter typical accuracy
• uBlox NEO-M8N GNSS receiver and integrated antenna
• Integrated real-time SBAS receiver (WAAS, EGNOS, etc.)
• 72 GNSS tracking channels
• Optional: uBlox NEO-M8T w/post-processing capability and external GNSS antenna passthrough connection for sub-meter accuracy

Barcode 1D/2D Imager (Barcode Models Only)

• Optional built-in barcode imager and decoder
• Symbologies: all common 1D and 2D (PDF417, MicroPDF417, Composite, RSS, TLC-39, Data matrix, QR code, Micro QR code, Aztec, MaxiCode, Postal codes, etc.)
• Programmable trigger buttons
• Visible aiming bullseye with low-light illumination
• Barcode Connector™ utility, wedge and configuration, SDK support available

UHF RFID (RFID Models Only)

• Optional built-in UHF RFID module and internal antenna
• Region-specific frequency configurations (859–873 MHz & 915–930 MHz)
• EPCglobal Gen 2 (ISO 18000-6C) protocol support
• Wide output range (0 dBm to +27 dBm)

Camera (Geo Models Only)

• Rear: 8 MP with LED illumination
• Front: 2 MP

Other Features

• Ambient light sensor
• Compass
• Accelerometer
• Gyroscope
• TPM (Trusted Platform Module) v2.0

Certifications & Standards

• FCC Class B
• CE Marking
• Industry Canada
• EN62368 Safety
• RoHS 2 Compliant
• Optional Class I, II, & III, Division 2, Groups A, B, C, D, F, G
• REACH
• Prop 65
• POP
• Canada Proposition
• TSCA (Toxic Substances Control Act)

Standard Accessories

• Standard removable battery
• AC wall charger with international plug kit
• Capacitive small-tip stylus w/tether
• Quick Start Guide
• Hand strap
• Connector port dust cover
• 2-year warranty

Configurations

Review

“The Mesa 3 is a true tool for the job, designed and built to survive the daily grind and hazards.”

— Conrad H. Blickenstorfer @ Rugged PC Review, October 2020

Video

Warranty

The Mesa 3 Windows Rugged Tablet comes with a two-year warranty. The warranty, provided by Juniper Systems, covers defects in materials and workmanship, under normal intended use, for a period of 24 months from the date of shipment. Accessories come with a similar 90-day warranty. The warranty is covered in more detail in the User’s Manual.
